OSD -
Nitinol corewire, X-ray visible highly flexible PU-tip

OSD

Construction

This guidewire has a Nitinol corewire with a X-ray visible highly flexible PU-tip. The shaft is uncoated. This guidewire is specially made for Oesophagus-Bougies and Oesophagus-Stent-Systems.

Ø - nominal diameter: standard 0.035 inch others on request

F - flexible on one side
flexible on two sides

I - lengths in cm: 50, 60, 65, 70, 75, 80,100, 125, 150, 180, 300, 400, 460; Others on request

J - tip: Standard 60°, others on reques

Tolerance Lengths +/- 5 mm
Diameter : +0/-0,03 mm

Customer requiresments
Besides our standards, we would be pleased to be your manufacturer when it comes to individual specifications and wishes

Configuration
Only the transport hose can be configured. This consists of PP or HDPE..

Dispenser

Accessories
Accessories are the dispenser, including the tube and clips. This can include further details as a rinsing attachment (Luer) or Introducer.

700703 Introducer
